This generator set is ideal for facilities that require a dependable power source for emergency and standby applications. Global Cummins support guarantees availability of spare parts and service wherever your operations are located.
CUMMINS 6LTAA9.5-G1 Technical Data.pdf
CUMMINS 6LTAA9.5-G1 Performance curve.pdf
Power Challenges in Critical Facilities
Unexpected power outages can disrupt commercial operations, compromise sensitive equipment, and cause financial losses. Facilities like hospitals, clinics, and data centers require a reliable backup power system to maintain continuous operation.
Reliable Solution with Cummins 6LTAA9.5-G1
The Cummins 6LTAA9.5-G1 diesel generator provides a dependable standby power solution for commercial buildings, medical centers, and other critical facilities. Its robust engine ensures stable voltage and frequency, supporting uninterrupted operations during power interruptions.
Engine Technical Specifications
DCEC 6LTAA9.5-G1-A generator drive engine is a 6-cylinders in line, 9.5 liter four-stroke engine equipped with mechanical fuel pump and electronic governor, comes with turbocharger and Air-Air intercooler. The prime power for 50 Hz generator set (1500 RPM) of DCEC 6LTAA9.5-G1-A is 290 kW.
DCEC 6LTAA9.5-G1-B generator drive engine is a 6-cylinders in line, 9.5 liter four-stroke engine with 114 mm bore and 145 mm stroke. Equipped with mechanical fuel pump and electronic governor, comes with turbocharger and Air-Air intercooler. The prime power for 60 Hz generator set (1800 RPM) of DCEC 6LTAA9.5-G1-B is 280 kW.
Key Advantages
Low-noise operation suitable for sensitive environments
Automatic transfer switch (ATS) compatible for seamless backup
Fuel-efficient engine with long runtime capability
Robust load response suitable for heavy-demand applications
Supported by Cummins global service network with easy access to spare parts
Technical Data
| Model | Cummins 6LTAA9.5-G1 |
| Rated Power (50Hz) | 290 kW / 362.5 kVA |
| Rated Power (60Hz) | 280 kW / 350 kVA |
| Voltage | 220V/380V/400V/480V (Customizable) |
| Frequency | 50Hz / 60Hz |
| Noise Level | ≤75dB at 7m |
| Engine Weight | 900 kg |
| Engine Dimensions (L × W × H) | 1650 × 800 × 1200 mm |
Typical Applications
Hospitals, medical centers, and clinics
Commercial office buildings and data centers
Critical backup for laboratories and research facilities
Emergency power supply for sensitive equipment
Why Choose DIOU POWER
DIOU POWER supplies Cummins diesel generator sets directly from the factory, providing competitive pricing, flexible configurations, and professional technical support. Every generator is tested to ensure reliable performance and long-term durability.
