Product Overview
The CCEC Cummins KTA38-G5 generator set is a heavy-duty, high-capacity diesel power solution designed to meet the rigorous demands of industrial, commercial, and critical infrastructure applications. Built around the robust CCEC KTA38-G5 generator drive engine, this genset combines Cummins' legendary engine reliability with advanced engineering to deliver consistent performance across standby, prime, and continuous power modes. Suitable for large-scale manufacturing, mining, data centers, hospitals, and public utilities, the KTA38-G5 generator set ensures uninterrupted power supply to protect against costly downtime and maintain operational efficiency.
Engine Technical Details
CCEC KTA38-G5 (1500 RPM) Generator Drive Engine is V Type 12-Cylinder, 37.8 liters (2300 in3) Four-Strokes Engine with 159 mm (6.25 in) Bore and 159 mm (6.25 in) Stroke.
KTA38-G5 Generator Drive Engine Equipped with Direct Injection CMI PT Fuel System, Comes with Turbocharged and Aftercooled. The Standby Power for 50 Hz Generator Set (1500 RPM) of CCEC KTA38-G5 Generator Drive Engine is 1300 HP (970 kW). The Prime Power for 50 Hz Generator Set (1500 RPM) of CCEC KTA38-G5 Generator Drive Engine is 1180 HP (880 kW). The Continuous Power for 50 Hz Generator Set (1500 RPM) of CCEC KTA38-G5 Generator Drive Engine is 880 HP (656 kW).
Key Features
Power Versatility: Offers three power ratings (970kW standby, 880kW prime, 656kW continuous) to adapt to diverse industrial power needs, making it a flexible solution for various scenarios.
Advanced Engine Technology: CCEC KTA38-G5 engine features V Type 12-Cylinder design, 37.8L displacement, direct injection CMI PT fuel system, and turbocharged & aftercooled configuration for optimal fuel efficiency and low emissions.
Industrial-Grade Durability: Heavy-duty steel frame, corrosion-resistant enclosure, and high-quality components ensure long service life in harsh operating environments (dusty, humid, high-temperature).
Cummins Global Support: Backed by Cummins' worldwide after-sales network, with easily accessible spare parts and professional technical service to minimize maintenance downtime.
Stable Performance: 1500 RPM constant speed operation, 50Hz frequency, and precise voltage regulation protect sensitive equipment from power fluctuations, ensuring reliable power supply.
Easy Maintenance: User-friendly design with easy access to filters, fuel tanks, and engine components, reducing maintenance costs and improving operational efficiency.
Technical Specifications
| Generator Model | CCEC Cummins KTA38-G5 |
| Engine Model | CCEC KTA38-G5 |
| Engine Type | V Type 12-Cylinder, Four-Stroke, Turbocharged & Aftercooled |
| Displacement | 37.8 liters (2300 in³) |
| Bore x Stroke | 159 mm (6.25 in) x 159 mm (6.25 in) |
| Fuel System | Direct Injection CMI PT Fuel System |
| Speed | 1500 RPM |
| Frequency | 50 Hz |
| Standby Power | 1300 HP (970 kW) |
| Prime Power | 1180 HP (880 kW) |
| Continuous Power | 880 HP (656 kW) |
| Voltage | 400V/480V (Customizable) |
Applications
Large Industrial Manufacturing Plants (heavy-duty production lines, factory backup power)
⛏️ Mining & Quarrying Sites (remote operation prime power, equipment power supply)
Data Centers & IT Infrastructure (critical continuous power, no downtime)
Hospitals & Public Utilities (emergency standby power, life-support equipment)
Commercial Complexes & High-Rise Buildings (standby power for elevators, lighting)
Construction Sites (temporary prime power for heavy machinery)
Why Choose DIOU POWER for CCEC Cummins KTA38-G5 Generator Set?
As a factory-direct supplier of Cummins-powered generator sets, DIOU POWER offers the CCEC Cummins KTA38-G5 generator set at competitive pricing with no middleman markup. We adhere to strict quality control standards, ensuring each unit undergoes rigorous testing before delivery to meet international industrial standards. Our team provides customized solutions (voltage, enclosure type, monitoring system) to match your specific project needs, along with fast global logistics support and comprehensive after-sales service. Backed by Cummins' global network, we ensure easy access to spare parts and professional technical assistance wherever your project is located. Choose DIOU POWER for reliable, high-performance power solutions that protect your business and keep your operations running smoothly.
Contact Us
For more information about the CCEC Cummins KTA38-G5 generator set, to request a quote, or to discuss your custom power needs, contact DIOU POWER today. Our professional team is ready to provide you with a tailored power solution.
